    Automatic Single Card Or Multi Card Packing Machine Card Wrapper PLC Controlled

    Ask Lasest Price
    Brand Name : YL
    Model Number : YUP-3000
    Price : Negotiable
    Payment Terms : T/T, Western Union, D/P, D/A
    Supply Ability : 1 set per 45 days
    Delivery Time : 50 working days
    • Product Details
    • Company Profile

    Automatic Single Card Or Multi Card Packing Machine Card Wrapper PLC Controlled

    Automatic High-speed Ultrasonic Card Packing Machine Technical Specification


    Automatic High-speed Ultrasonic Card Packing Machine Card Packaging Machine Card Wrapping Machine Card Wrapper Card Packer YUP-3000


    1. Introduction of Automatic High-speed Ultrasonic Card Packing Machine Technical Specification


    Automatic High-speed Ultrasonic Card Packing Machine YUP-3000 can realize perfect single-card or multi-card packing by applying continuous ultrasonic welding technology in a very high speed. PLC controlled with friendly man-machine interface, it features faster speed, low noise, perfect welded pattern and reliable performance. It is applicable to pack cell phone charge card, standard and smaller SIM card in bulk.


    Automatic Single Card Or Multi Card Packing Machine Card Wrapper PLC Controlled


    2. Key Features:


    1. Packing film is conveyed by special rubber wheel and air absorbing belt to ensure flat and stable film.
    2. It has the function of automatic checking for card overlapping and card absence. If the above occurs, it will stop automatically with error notice.

    3. The second feeder can be installed to pack double cards or insert the mini booklet in one bag.
    4. It applies the welding technology of continuous ultrasonic welding, which can ensure clear and beautiful sealing patterns or lines.

    5. Single-card packing or Multiple-card packing is available, and the number of cards to be collected can be set.
    6. Visual inspection system is optional, which can check the serial number or bar codes of the cards.

    7. Chain card binding unit is optional, which can bind the packed chain cards.


    Automatic Single Card Or Multi Card Packing Machine Card Wrapper PLC Controlled


    3. Technical Parameters of Card Packer YUP-3000


    Power SupplyAC 380V/50 HZControl MethodPLC programming+ Step System
    Total Power5KWOperator1 person
    Air Source6 kg/c㎡(Dry)DimensionL4800×W980×H1860mm
    Air Consumption50L/minPackaging Material

    BOPP film or similar

    0.025mm~0.035 mm thick

    WeightApproximate 1000KgCard size0.25-0.8mm thick CR80 cards
    SpeedMax 30000 pcs/hrPackaging SizeFolded film 120 mm wide (for standard card ) or 60mm wide (for half size card), Film roll inner diameter 3 inches and external diameter less than 450 mm,
    1. ) Dimension: total around L4800×W980×H1860mm
    2. ) Weight:Around 1000 KG
    3. ) Power supply:AC 380V/50 HZ
    4. ) Rated Power: 5 KW
    5. ) Compressed Air:50 L/min 6 kgs /cm2(Dry)
    6. ) Control Mode:PLC programming+ Step System
    7. ) Processed Card size:ISO 0.25-0.8mm thick CR80 cards
